MPR 1500/15 Diesel engine
Trailer fire pump
Characteristics
- Flowrate : 1500 litres/minute
- Pressure : 10 to 15 bars
- Height : 3m
- Dimensions : Length: 3.200m / Width: 1.400m / Height: 1.390m
- Service weight : 750kg
Specific features
PUMP
HAKA pumps – Type GB 90/15 AE
- Single-cell centrifugal pumps.
- Suction : 1xND100 fitted with a 1/2 AR coupling with filter + plug and bead chain.
- Discharge : 2 to 5 mushroom valves or ¼ turn valves fitted with ½ DSP couplings ND65 and/or ND100 with plugs and bead chains.
- Primer : fitted with an electric motor and a rotary vane vacuum pump, designed to operate without water and oil.
- Option : water ring primer.
The power pump is fitted with an electronic pump pressure control system.
MOTORISATION
PEUGEOT engine — Type DV6 TD
- Electronic injection.
- Power : 68 kw at 6000 rpm - 1560 cm3.
- Cooling : self-contained closed-cycle, with a radiator fitted with two electric fans.
- Electronic ignition system – Battery main switch, emergency stop push-button
- Stainless steel gas tank – autonomy 2 hrs.
